| Model | HQSD-210KBI41 | HQSD-285KBI40 | HQSD-360KBI40 | HQSD-460KBI40 | ||
| Nominal Input（W） | 870 | 1530 | 1605 | 1770 | ||
| Power Supply | 220V 50/60 Hz | |||||
| Refrigerant | R404A | |||||
| Refrigerant Max.（Kg） | 1.8 | 2.5 | 3.5 | 3.5 | ||
| Max Running Current (A) | 6 | 10.5 | 12 | 14.0 | ||
| Evap.Temp(℃) | -40～-5℃ | |||||
| Ambient Temp(℃) | 10～43℃ | |||||
| Compressor（Model） | JHSD150Z312 | KHSD203Z312 | KHSD300Z312 | KHSD300Z312 | ||
| Condebser | Style | 5排4.5环 | 5排4.5环 | 5排4.5环 | 5排4.5环 | |
| Fam Motor | （mm）Diameter Quantity | φ230*2 (EC) | φ230*3 ((EC)) | φ230*3 ((EC)) | φ230*4 ((EC)) | |
| (m3/hr) Air Flow | 820*2 | 820*3 | 820*3 | 820*4 | ||
| (mm) Pipe | Gas Inlet Diam | φ12.7(1/2″) | ||||
| Liquid Outlet | φ9.53(3/8″) | |||||
| (mm) Out Dimension | (mm) Length | 680 | 940 | 1145 | 1350 | |
| (mm) Width | 710 | 620 | 620 | 620 | ||
| (mm) Height | 263 | |||||
| （Kg）Weight | 33.5 | 47 | 53 | 62 | ||
| （W） Capacity | (℃) Evap Temp | Ambient Temp:32℃ | ||||
| -40 | 565 | 860 | 970 | 1100 | ||
| -35 | 715 | 1065 | 1240 | 1415 | ||
| -30 | 905 | 1295 | 1500 | 1790 | ||
| -25 | 1090 | 1705 | 1885 | 2160 | ||
| -20 | 1400 | 1925 | 2200 | 2695 | ||
| -15 | 1675 | 2285 | 2690 | 3090 | ||
| -10 | 1965 | 2710 | 3225 | 3935 | ||
| -5 | 2300 | 3030 | 3850 | 4730 | ||
| Wiring Capacity | Leak Protector | (A) Rated Current | 15 | 20 | 20 | 20 |
| (mA) Leak Current | 30 | 30 | 30 | 30 | ||
| (mm2) Diameter | L≤10m | 2.0 | 4.0 | 4.0 | 4.0 | |
| 10＜L≤20m | 2.5 | 6.0 | 6.0 | 6.0 | ||
| 20＜L≤30m | 2.5 | 6.0 | 6.0 | 6.0 | ||
| (GB/T 21363-2008)TEST CONDITION: | ||||||
| TEST CATION | AMBIENT TEMP. | RETURN GAS TEMP. | EVAP. TEMP. | TESTING POWER SUPPLY | ||
| ① | （3600rpm） Standard test conditions | 32.2℃ | 5℃ | -23℃ | 220V～50HZ | |
| ② | OVERLOAD RUNNING | 43℃ | 18℃ | -7℃ | 220V～50HZ | |
